Project
501 Alliance Avenue
A four-storey, 65,000 sq ft building plus an adjacent 54,000 sq ft single-storey structure in central Toronto, converted to geothermal — and the building where the heat pumps themselves are manufactured.
The brief
Heat and cool 119,000 sq ft without a mechanical yard
A dense urban site with no room for a conventional condenser farm, an owner who wanted the operating cost down, and a LEED target that the mechanical system would either make or break.
What we did
Eighteen 15-ton Polar Bear water-to-water heat pumps, built in the building they now heat, using Copeland compressors and packless water coils. The field is vertical — the only option on a site like this — drilled to 192 metres.
The boreholes were deliberately drilled off the vertical axis, which fans the field outward underground and buys roughly 10% more thermal footprint from the same patch of surface. On a constrained urban lot, that is the difference between the loop fitting and the project dying.
Perimeter ice melt was built in — passive and active — because a building that heats itself from the ground may as well stop paying someone to salt the entrance.
The result worth quoting
The geothermal system supplied 39 of the 80 points required for the building's LEED Gold certification — close to half the certification, from the mechanical system alone. Capacity for a further 45 tons was left provisioned for future load.
Watch the walk-through
A tour of the retrofit, filmed on site.
Good equipment is only part of a smart installation. Good engineering and installation practices are also required.
Dennis Campbell, President, Polar Bear Water Source Heat Pump Mfg. Inc.
Another one
315–325 University Ave W, Cobourg
A four-storey residential building over underground parking — engineered end to end, from the underground services to the shared heat pump loop feeding every suite.
